The size range of C11000 electrolytic copper plate needs to be comprehensively judged in combination with the specific product type and production standards:
Thickness range:
The thickness of conventional plates is 0.1mm to 200mm, but the common thickness of spot products is 0.3mm to 150mm. Some special-purpose plates (such as electroplating) can be as thin as 0.01mm or as thick as 120mm. The standard thickness of electrolytic cathode plates is 10-12mm, and the thickness of large plates used in smelters is about 12mm.
Width range:
The width of the plates spans a large range, from 6mm to 3100mm, but the conventional supply width is 200-3100mm. Common widths in spot products include 305-1000mm and 600-2000mm, and the width of electrolytic cathode plates is mostly 900-1000mm.
Length range:
The theoretical maximum length is 12 meters (12000mm), but the actual supply is usually ≤8100mm, and customized products can be cut as needed. The common lengths in stock are 1200-8000mm, and the standard length of the electrolytic cathode plate is 914mm (3 feet) or 1000mm.
C11000 is a high-purity electrolytic copper (ETP copper), the main components and impurity upper limits are as follows:
Copper + Silver (Cu + Ag): ≥99.90%
Impurity elements (unit: %, maximum value):
Tin (Sn) ≤0.002
Zinc (Zn) ≤0.005
Lead (Pb) ≤0.005
Nickel (Ni) ≤0.005
Iron (Fe) ≤0.005
Antimony (Sb) ≤0.002
Sulfur (S) ≤0.005
Arsenic (As) ≤0.002
Bismuth (Bi) ≤0.001
Oxygen (O) ≤0.06
Total of other impurities ≤0.1
The mechanical properties of C11000 vary greatly due to processing conditions (such as annealing and cold hardening). The comprehensive data are as follows:
1. Tensile Strength
Annealed state: 200-275 MPa
Cold hardening state: 275-410 MPa
Extreme cold working (such as hard state): up to 500 MPa (converted to ksi about 50)
2. Yield Strength
Annealed state: 50-100 MPa
Cold work hardening state: 100-390 MPa
3. Elongation
Annealed state: δ10≥5%, δ5≥10%; some data are 20-50%
Cold work hardening state: elongation is significantly reduced, such as hard state (H04) is only 2-5%
4. Hardness
Vickers hardness (HV): 40-110 HV (annealing to cold work hardening)
Rockwell hardness (HRF): 65-80 HRF (hard state)
5. Other properties
Elastic modulus: 115-117 GPa
Shear strength: 150-230 MPa
Fatigue strength: excellent
C11000 electrolytic copper plate production process
1. Raw material preparation and electrolytic refining
Copper anode plate processing: Using copper anode plates (containing more than 98.5% copper) as raw materials, impurities are removed through electrolytic refining process. Under the action of direct current, the electrolyte (copper sulfate solution) deposits copper ions at the cathode to form high-purity cathode copper (purity of more than 99.99%).
Electrolyte circulation: The electrolyte is heated by circulating through high-level tanks and plate heat exchangers, and byproducts such as copper sulfate and nickel are recovered in the steps of vacuum evaporation and water-cooling crystallization to achieve efficient resource utilization.
Residual anode treatment: The residual anode after electrolysis is returned to the smelting workshop for reuse after washing, and the anode mud is filtered to recover precious metals.
2. Processing and forming
Melting and rolling: The cathode copper is formed after melting and casting, and the surface oxide is removed by milling, and then hot rolling or cold rolling is performed to refine the size.
Stretching process: Use triple stretching, coil stretching and other stretching processes to enhance material strength and toughness to meet different industrial needs.
Annealing treatment: Improve grain structure and mechanical properties through online annealing, and restore ductility after cold processing.
3. Inspection and packaging
Quality inspection: Including spectrometer component analysis, eddy current flaw detection, size inspection, etc., to ensure that the product meets ASTM, GB and other standards.
Finished product storage: After cutting to size and surface treatment, it is packaged and stored, and customized specifications are supported (such as thickness 0.1-120mm, width 2-2500mm).
Our product advantages
1. Material performance advantages
Ultra-high purity: copper content ≥99.90%, impurities (oxygen, sulfur, etc.) are strictly controlled below 0.005%, meeting the high purity requirements of electrical applications.
Excellent conductivity: conductivity ≥100% IACS (International Annealed Copper Standard), some products can reach 101% IACS, suitable for high current density scenarios.
Excellent thermal conductivity: thermal conductivity 394-401 W/(m·K), suitable for heat exchangers, radiators and other thermal management components.
Corrosion resistance: stable in the atmosphere and fresh water, but avoid oxidizing acid environments.
2. Processing and application advantages
Processing performance: supports cold/hot processing, welding, brazing, can be made into various forms such as plates, bars, pipes, etc., adapted to complex industrial needs.
Wide applicability: covers power (cables, busbars), electronics (circuit boards, connectors), chemicals (pipelines, valves), construction (decorative materials) and new energy (solar panels) and other fields.
3. Factory production and service advantages
Standardized production: in line with international standards such as ASTM, DIN, JIS, and SGS certification to ensure global market compatibility.
Flexible supply: providing spot wholesale (such as German Cu-OFE oxygen-free copper, American standard C11000 plate) and customized services, with a short delivery cycle (within 7 working days).
Environmentally friendly and sustainable: electrolyte recycling, residual anode recovery rate of 100%, in line with the concept of green manufacturing.
4. Technical parameter guarantee
Current density control: 100-200 A/m², voltage 0.2-0.5V, optimize electrolysis efficiency.
Stable mechanical properties: tensile strength 200-360 MPa, elongation 2-40%, meet high-precision processing needs
Q1:Do you provide samples? Is it free or extra?
A1:Yes, we can provide samples free of charge and the customer will pay the freight.
Q2:What if I don't have export experience ?
A2:We have reliable forwarder agent which can ship items to you by sea/air/Express to your doorstep. Any way, we will help you choose the most suitable shipping service.
Q3:How long is your lead time?
A3:If it is in stock, it is usually 5-10 days. Or, if there is no inventory, 15 days, depending on the quantity.
Q4:What are your terms of payment?
A4:30% T/T deposit in advance, 70% T/T balance within 5 days after B/L copy, 100%.Irrevocable L/C at sight, 100% Irrevocable L/C after receive B/L 30-120 days, O/A.
Q5:How is your technical support?
A5:We provide lifetime online support through Whatsapp/ Skype/ Wechat/ Email. Any problem after delivery, we will offer you call anytime.
