Size range
Thickness range: 3.0 mm to extra-thick specifications (such as 50 mm), common thicknesses include 3.0 mm, 5.0 mm, 20 mm, 30 mm, etc., support on-demand cutting.
Width and length: The width is usually 1219 mm, and the length can be customized according to needs.
International Standards
ASTM Standards:
Copper Plate: Meets ASTM B152 standards, covering chemical composition, mechanical properties and dimensional tolerances.
EN Standards:
Copper Plate/Copper Strip follows EN 1652 (corresponding to DIN 1787), with thickness ranging from 0.006 mm to 50 mm, and width graded by thickness (e.g. 0.5-0.8 mm width ≤ 600 mm).
C18150 is based on copper, and its main alloy components are chromium (Cr) and zirconium (Zr). The specific ranges are as follows:
Copper (Cu): ≥99.70% (remainder)
Chromium (Cr): 0.50–1.50%
Zirconium (Zr): 0.05–0.25%
Other elements: The total amount of impurities such as iron (Fe), silicon (Si), phosphorus (P) does not exceed 0.50%.
Mechanical properties vary significantly depending on the heat treatment state (such as annealing, cold working, aging):
Typical aged state properties:
Tensile strength: 480–700 MPa
Yield strength: 380–520 MPa
Elongation: 8–20%
Hardness:
Rockwell hardness (HRB): 75–88
Brinell hardness (HB): 130–147
Vickers hardness (HV): 150–200
Comparison of different processing states (for example):
1/2H state: tensile strength 480–560 MPa, elongation ≥8%
H state: tensile strength 540–630 MPa, elongation ≥4%
SH state: tensile strength 600–700 MPa, elongation ≥2%
High temperature properties:
Softening temperature: ≥500°C (much higher than 200°C for pure copper and 350°C for silver-containing copper)
Thermal conductivity: 180–330 W/m·K
Coefficient of thermal expansion: 9.5×10⁻⁶/°F (77–212°F) or 16.45×10⁻⁶/K (0–250°C)
III. Electrical conductivity and physical properties
Electrical conductivity:
Annealed state: 80% IACS (International Annealed Copper Standard)
Aged state: 55–65% IACS
Density: 8.85–8.95 g/cm³
Melting point: Liquidus 1080°C, solidus 1070°C
Production process and product advantages of C18150 copper plate and copper strip/coil:
1. Production process
Forming process
The blank is prepared by melting and casting process, using cathode copper (purity ≥99.99%) and chromium, zirconium and other alloy elements to smelt, and the chromium content is controlled to 0.5-1.5% and zirconium to 0.05-0.25%.
The continuous extrusion (Conform Extrusion) technology is used in the hot working stage to extrude the blank from 12.5mm diameter to a smaller size (such as 8-10mm), significantly refining the grain and improving the mechanical properties.
Cold working includes rolling, cold heading, machining, etc., and the surface roughness (up to 1.64μm) and material removal rate are optimized by controlling the plate thickness, cooling speed and processing parameters (such as cutting speed 1200rpm, feed rate 0.06mm/rev).
The heat treatment adopts solid solution treatment + artificial aging (such as AT and HT processes) to improve the hardness (HRB 80) and softening temperature (>500°C).
Processing adaptability
Supports conventional metal processing technologies such as welding (arc welding, brazing), bending, and stamping, but oxyacetylene welding is not recommended.
High-speed milling pretreatment is required during discharge machining to reduce electrode loss.
2. Product advantages
High strength and high electrical/thermal conductivity
Tensile strength reaches 550-700MPa (depending on the state), electrical conductivity ≥80%IACS, thermal conductivity 320-330W/m·K, with high strength and high conductivity, better than traditional alloys such as C7025 and C19400.
At the same conductivity, the cost is only 54% of C7025, with significant cost performance.
High temperature resistance and wear resistance
Softening temperature >500°C (better than 200°C of pure copper and 350°C of silver-containing copper), and stable performance is maintained at high temperature.
Hardness reaches 170-200HV, excellent wear resistance, suitable for high-load scenarios (such as resistance welding electrodes and molds).
Processing and anti-deformation performance
Good cold and hot processing formability, high stress relaxation resistance, and thin sheet processing is not easy to bend.
Chromium elements improve cutting performance, reduce processing adhesion, and extend tool life.
Wide application
Applicable to high-end fields such as high-current connectors, new energy vehicle charging and discharging systems, and high-speed rail motor end rings.
