Size range
Thickness:
The thickness range of copper strip/coil is 0.01–2.5mm, and common specifications include 0.05mm, 0.1mm, 0.2mm, 0.3mm, 0.5mm, 1.0mm, etc., and supports strip customization.
Width:
The standard width is 20–2000mm, and different widths can be customized according to needs.
Other parameters:
The inner diameter of the coil is commonly 80–500mm, and the single weight of the coil can reach 14kg/mm.
International standards
C17500 mainly follows the following international standards:
ASTM standard: ASTM C17500/C17510, covering chemical composition, mechanical properties and processing requirements.
EU standard: Refer to European specifications such as BS EN 1652, and compatible with GB/T 2059-2008 Chinese national standard.
Main components:
Copper (Cu): Balance (usually about 93.5%-99.5%).
Beryllium (Be): 0.4%-0.7%
Cobalt (Co): 2.4%-2.7% (key strengthening element).
Nickel (Ni): Some sources mention trace amounts (such as 0.1%-0.15%)
Impurity limits:
Iron (Fe) ≤0.10%, Silicon (Si) ≤0.20%, Aluminum (Al) ≤0.20%, Lead (Pb) ≤0.005%.
Mechanical properties
Strength and hardness:
Tensile strength: 700-1200 MPa, up to 940-1035 MPa after aging treatment.
Yield strength: 560-1050 MPa (up to 951 MPa after aging).
Hardness:
Untreated state: ≤50 HB (Brinell hardness);
After aging: 38-44 HRC (Rockwell hardness) or 92-100 HRB.
Electrical and thermal conductivity:
Electrical conductivity: 45%-65% IACS (International Annealed Copper Standard), significantly higher than ordinary copper.
Thermal conductivity: 105-208 W/(m·℃), suitable for heat dissipation scenarios.
Elongation and toughness:
Elongation: 10%-25% (may drop to 1% after cold working).
Elastic modulus: 128-138 GPa, showing high elasticity.
3. Other key features
Corrosion resistance: Excellent in fresh water, sea water and dilute acid, but prone to corrosion in humid ammonia and nitric acid environments.
Processing performance:
Good hot processing performance, can be hot extruded and hot rolled; excellent cold processing performance, suitable for stamping, bending, etc.
Machinability is 20% of ordinary materials, which can be improved after aging.
Special properties: non-magnetic, anti-adhesion, no sparks on impact, suitable for explosion-proof scenes.
C17500 copper strip and copper coil production process and product advantages:
Production process
Basic processing flow
The production of C17500 copper strip/coil mainly adopts the continuous extrusion process of copper alloy. The raw material Φ20 copper rod is heated and deformed by continuous extrusion method, and then cooled by circulating water to form billet. Some production processes also involve induction melting, vertical semi-continuous casting, hot rolling, cold rolling, bright annealing and other steps to ensure the high precision and uniform structure of the product. Specific processes also include quenching and tempering treatment (aging hardening), which significantly improves the strength, hardness and other properties of the material through solid solution and aging treatment.
Key process features
Cold/hot processing performance: C17500 has excellent cold processing performance and good hot processing performance. It can be processed into complex shapes by various forming methods such as rolling and stamping.
Heat treatment: After quenching, the material undergoes aging treatment (such as tempering) to precipitate strengthening phases, achieving high strength (tensile strength 794-1105 MPa), high hardness (Brinell hardness 220 HB or HRC 38-44) and other characteristics.
Surface treatment: Some processes include bright annealing to ensure excellent surface quality, suitable for precision electronic components.
Product advantages
Mechanical properties
High strength and high elasticity: tensile strength can reach 794-1105 MPa, yield strength 620-1035 MPa, suitable for springs, elastic elements, etc.
Wear resistance and fatigue resistance: suitable for high wear scenarios such as molds, bearings, valves, etc.
Physical and chemical properties
Electrical conductivity/thermal conductivity: electrical conductivity 45% IACS, thermal conductivity 208-315 W/m·K, better than ordinary copper alloys, suitable for electrodes and welding equipment.
Corrosion resistance: Excellent corrosion resistance in the atmosphere, fresh water, and seawater, but strong corrosive media such as moist ammonia and nitric acid must be avoided.
High and low temperature resistance: It can maintain stable performance at extreme temperatures, is non-magnetic and has no sparks when impacted, and is suitable for explosion-proof tools and aerospace.
Processing and application advantages
Easy welding and brazing: It supports a variety of methods such as soldering, resistance welding, and laser welding to meet the needs of complex components.
Wide applicability: It is used in fuses, electrical connectors, molds, automotive parts, medical devices and other fields.
Q1:Do you provide samples? Is it free or extra?
A1:Yes, we can provide samples free of charge and the customer will pay the freight.
Q2:What if I don't have export experience ?
A2:We have reliable forwarder agent which can ship items to you by sea/air/Express to your doorstep. Any way, we will help you choose the most suitable shipping service.
Q3:How long is your lead time?
A3:If it is in stock, it is usually 5-10 days. Or, if there is no inventory, 15 days, depending on the quantity.
Q4:What are your terms of payment?
A4:30% T/T deposit in advance, 70% T/T balance within 5 days after B/L copy, 100%.Irrevocable L/C at sight, 100% Irrevocable L/C after receive B/L 30-120 days, O/A.
Q5:How is your technical support?
A5:We provide lifetime online support through Whatsapp/ Skype/ Wechat/ Email. Any problem after delivery, we will offer you call anytime.
